6.4 PCB number
The PCB number is located next to the power
terminal block.
6.5 Connector plate
Standard connector plate (all models)
Note: The drawing below shows the maximum number of connectors and cable grips. The actual
number of connector depends on the model number (HygroFlex 1, 2 or 3).
