12 Specifications
Operating Voltage standard 12 to 35 VDC / 300 mA max.
or 12 to 24 VAC
optional 90 to 264 VAC 50/60 Hz
Operating limits at electronics 0…99 %RH (non condensing)
w/o LC display -40...60°C (-40...140°F)
with LC display -30…60°C (-22…140°F)
Measured parameters
1)
relative humidity typical range 0…100 %RH
indication range 0.0 to 100.0 %RH
temperature
typical ranges 0…100 °C, -50…150°C, 0…200°C
0…100 °F, -50…250°F, 0…400°F
indication range -99.9 to 999.9 °C or °F
barometric pressure
2)
typical range 0…2000 hPa / 0…50 PSI / 0…100 InHg
indication range 0.000 to 9999 hPa/PSI/InHg
Calculated parameters
1) 2)
dew / frost point
3)
typical range -50…100 °C / -50…200°F
indication range -99.9 to 999.9 °C or °F
wet bulb temperature
4)
typical range 0…100°C / 0…200°F
indication range 0.0 to 100.0°C / 32 to 212.0°F
enthalpy
4)
typical range -50…250 J/g or -50...150 BTU/lb
indication range -99.9 to 9999 J/g or BTU
vapor concentration typical range 0…500 g/m3 or 0…250 gr/cuft
indication range 0.000 to 9999 g/m3 or gr/cuft
specific humidity
4)
typical range 0…500 g/kg or 0…4000 gr/lb
indication range 0.000 to 9999 g/kg or gr/lb
mixing ratio
4)
typical range 0…500 g/kg or 0…4000 gr/lb
indication range 0.000 to 9999 g/kg or gr/lb
vapor concentration at saturation typical range 0…500 g/m3 or 0…250 gr/cuft
indication range 0.000 to 9999 g/m3 or gr/cuft
part. pressure of water vapor typical range 0…500 hPa / 0…10 PSI / 0…20 InHg
indication range 0.000 to 9999 hPa / PSI / InHg
sat. pressure of water vapor typical range 0…500 hPa / 0…10 PSI / 0…20 InHg
indication range 0.000 to 9999 hPa / PSI / InHg
System accuracy at 23°C/73°F ± 1 %RH
with HygroClip probe & 4-point calibration ± 0.2°C / 0.4°F
Number of probe inputs HygroFlex 1 1
HygroFlex 2 and 3 1 (standard) or 2 (optional)
Probe type
5)
all models ROTRONIC HygroClip digital probe
HygroFlex 2 and 3 ROTRONIC analog probe
6)
Third-party analog probe
6)
