Maintenance 4-32 HP6A Manual
12 Lift pivot block assembly and remove from inside of pivot arm.
13 Replace pivot block assembly and reverse above procedure to reassemble. Make certain that flat on
pivot pin aligns with set screw. Apply Loctite to set screw and pivot block bolts.
14 After hone is reassembled adjust upper sensor actuator bolt per instructions in maintenance section
of this manual.
