GUI Elements Description / Options
Subnet
This option is only available when the IP Method is set to Static.
• Manually set the subnet mask
Gateway
This option is only available when the IP Method is set to Static.
• Manually set the gateway address for the UC-IVB-50 to communicate with
another network
Apply
Click to save and apply any IP setting changes. The LAN module will reboot auto-
matically once the IP settings are saved.
IP Conict Detection
Enable this option to detect when a conicting IP address has been detected
on the network that can cause issues in operation of the UC-IVB-50. When this
option is enabled, a brief OSD message will appear on the connected display
when a conict has been detected and will continue to appear at timed intervals
until the issue is corrected. When using DHCP as the IP method, rebooting the
UC-IVB-50 should resolve the issue as a new IP address that is not in coict
should be assigned.
HTPS
• On (Default): Use encrypted HTTP to access the Web GUI. Click the Apply but-
ton to immediately redirect the browser to the HTTPS Web page.
• O: Use unencrypted HTTP to access with the Web GUI. Click the Apply but-
ton to immediately redirect the browser to the HTTP Web page.
HTTPS Certicate
Use this option to open an explorer window and select a custom SSL certicate to
upload to the UC-IVB-50.
Private Key
Password
Please enter the private key password used in conjunction with the SSL certicate
that is being uploaded.
Upload
Press the Upload button to send the selected SSL certicate and encrypted pass-
word to the UC-IVB-50.
Restore the Default
Certicate
Use this button to restore the default factory certicate that is provided by the
UC-IVB-50.
