RuggON VX-601 - External Connectors Pin Assignments; Power Connector; RS-232;422;485 Port (COM1)

VX-601
V1.2
30
External Connectors Pin Assignments
Use this section as a reference for the pin assignments of the various ports available on the
VX-601.
Power Connector
Pin
Signal
1
DC+
2
DC-
3
GND
Note: Please refer the Chapter 4 section 1 for the external power cable to connect to power
source.
RS-232/422/485 Port (COM1)
1.
2.
3.
