RuggON VX-601 - GPIO, CANbus and DR Port

VX-601
V1.1
32
GPIO, CANbus and DR Port
Pin
Signal
1
CAN_H
2
J1850_BUS+
3
K_LINE
4
FWD
5
WHEELTICK
6
CAN_L
7
J1850_BUS-
8
L_LINE
9
NC
10
GND
11
IO_GND
12
DIO_OUT1
13
DIO_IN1
14
DIO_IN2
15
DIO_OUT2
