PC and ERT Control/Gating Module
Revision C, August 2013
3-11
enough not to get false gates, then slowly increase one of the amplitudes until
gates begin to be missed. Final setting of 30 - 50% of max works well with auto
detection threshold and 60 – 80% for manual detection threshold.
The auto detection threshold is a proprietary additional detection criterion. To turn it
off, select manual and set the threshold to the positive slope amplitude.
CHARGER window
The CHARGER window reports the current status of the IBP Module power, the IBP
internal battery and the external charging battery (i.e. the ERT Battery Pack) if one is
connected to the ERT Control/Gating Module’s battery charger.
.
