Trends
Revision C, August 2013
7-7
Item #
Label
Unit
explanation
39
USER Period
ms
period from USER Resp channel
40
Pambient
mmHg
ambient barometric pressure
41
Temp; 2
ºC or F
temperature from channel 2
42
Event
text
users text message input
43
Vbatt
volts
battery voltage of ERT Battery Pack
44
Voffset
volts
offset voltage of ECG leads measurement
45
Chg Vplus
volts
Respiration Module’s operating voltage
46
Chg Vbint
Volts
voltage for the Resp Module’s internal battery
47
Chg Vbext
Volts
voltage for an external battery being charged
48
Chg Ipwm
mA
charging current for an external battery
49
Resp Gain
number
auto gain setting for the respiration channel
50
USER Gain
number
gain setting from USER Resp channel
51
Ox Monitor
level
auto gain level for oximeter measurement
52
ECGT
Rev #
ECGT software revision number
53
ETGate
Rev #
ETGate software revision number
54
PCcom
Rev #
PC com software revision number
55
RFcom
Rev #
RFcom software revision number
56
Resp
Rev #
respiration software revision number
57
Oximeter
Rev #
oximeter software revision number
58
FOT Rev
Rev #
Fiber Optic Temperature Module software rev
59
IBP
Rev #
IBP software revision number
60
Chg Rev
Rev #
battery charger software revision number
61
capnograph
Rev #
capnograph software revision number
62
Vent Rev
Rev #
ventilator software revision number
63
CVcom
Rev #
Capno/ventilator software revision number
64
POX Rev
Rev #
oximeter software revision number
65
FOT Rev
Rev #
fiber optic temp software revision number
66
ECG-Temp
flags
proprietary data for service
67
Resp
flags
proprietary data for service
68
Oximeter
flags
proprietary data for service
69
FOT Flags
flags
proprietary data for service
70
IBP
flags
proprietary data for service
71
Chg Flags
flags
proprietary data for service
72
Capno/vent
flags
proprietary data for service
73
Aux/FO in
flags
proprietary data for service
74
PCcom
flags
proprietary data for service
75
Number FOTs
number
number of fiber optic temperature channels
76
Plet signal
number
signal strength from the Oximeter Module
Note that as of the date of this manual, location 41 is not active. This locations has
been reserved for future implementation of a second channel of thermister temperature.
