2.9 Installation Cables
2.9.1 R4 Transponder Data Cable
Type: 15-Pair x 0,25 mm Shield – Wire AWG 24
Length: 2000 mm
Connector: 50-pole HD DSUB(female)
2.9.2 R4 Transponder Power cable
Type: 4-Pair x 0.5 mm
2
– Wire AWG 20
Length: 2000 mm
Connector: 9-pole DSUB(female)
2.9.3 R4 Display Data Cable
Type: 6-Pair x 0,25 mm Shield – Wire AWG 24
Length: 2000 mm
Connector: ConXall Maxi-Con-18pin(female)
2.9.4 R4 Display Power cable
Type: –3 x 0.5 mm
2
– Wire AWG 20
Length: 2000 mm
Connector: ConXall, Mini-Con-3pin(female)
2.9.5 VHF antenna cable
Type: See Appendix [A.6] – VHF-cable selector
Length: See Appendix [A.6] – VHF-cable selector
Connector: BNC (Female)
2.9.6 GPS antenna cable
Type: See Appendix [A.5] – GPS-cable selector
Length: See Appendix [A.5] – GPS-cable selector
Connector: TNC (Female)
