Mounting Page 8
Document id: 7000 108-011 A2
avoid power and voltage drops in the feed line it is important that
sufficient size of cable is used.
Install according to section 2.7.2.
2.2.6 Transponder status LED:s
The green LED indicates that power is applied to the R4 transponder.
A flashing yellow LED indicates that the R4 Transponder is
receiving data. A flashing red LED indicates that the R4 Transponder
is transmitting on the radio link (transmission starts approximately 1
minute after power on).
