Technical Specifications Page 52
Document id: 7000 108-011 A2
VHF TRANSCEIVER
Receivers: 156 – 163 MHz, selectable in 12.5 kHz steps (TDMA)
156.525 MHz fixed (DSC, Channel 70)
Transmitter: 156 – 163 MHz, selectable in 12.5 kHz steps
Channel bandwidth: 12.5 and 25 kHz
Output Power: High: 12.5 W
Low: 2 W
VHF antenna connector: BNC-Female
INTERNAL GPS RECEIVER
Type: L1, C/A Code, 12 Channel
Update rate: Once per second
Accuracy: < 2 meters, Horizontal, 2 sigma (95%), DGPS
< 30 meters, Horizontal, 2 sigma (95%), GPS
The position outputs meets accuracy specification
under dynamic conditions of 500 m/s and linear
acceleration of up to ±4g.
Antenna feeding: 5 VDC
GPS Antenna connector: TNC-Female
3.2 R4 Display
PHYSICAL
Dimensions: Height: 207 millimeters
Width: 270 millimeters
Depth: 102millimeters
Weight: 1,1 kilograms
POWER
Input Voltage: 24 VDC
Current need: 0,35 A (8,4 W) @ 24 VDC input
ENVIRONMENTAL
Temperature: -15°C to +55°C (Operational)
-55°C to +85°C (Storage)
Vibrations: IEC 60945 ed. 4.
EMC: IEC 60945 ed. 4
Radio Type Approval: IEC 61993-2
Compass Safe Distance: 53cm @ 0.094 uT (5.4°/H) and
28 cm @ 0.313 uT (18°/H)
