Technical Specifications Page 51
Document id: 7000 108-011 A2
3 TECHNICAL SPECIFICATIONS
3.1 R4 Transponder
PHYSICAL
Dimensions: Height: 85 millimeters
Width: 144 millimeters
Depth: 226 millimeters
Weight: 2.3 kilograms
POWER
Input Voltage: 24 VDC
The primary side of the transponder is
floating with reference to chassis.
Current need: Transmit:
2.3 A (55 W) @ 24 VDC input
Receive:
0.7 A (16 W) @ 24 VDC input
ENVIRONMENTAL
Temperature: -15°C to +55°C (Operational)
-55°C to +85°C (Storage)
Vibrations: IEC 60945 ed. 4.
EMC: IEC 60945 ed. 4
Radio Type Approval: IEC 61993-2
Compass Safe Distance: 15 cm @ 0.094 uT (5.4°/H) and
9 cm @ 0.313 uT (18°/H)
