6 DESCRIPTION OF CONTROLS
6.1 Controls
The appliance is equipped with the following controls:
• Power button
• Control panel
6.1.1 Power button
When the machine is connected to the electric network and the
all-pole switch is set to “I”, the following situations may happen when
operating the power button:
• Power button set to “0”, the control panel is off.
• Power button set to “I”, the control panel is on.
The fact that the power button is set to
“0” does not represent a guarantee that
the machine is not powered.
When performing any kind of cleaning or
maintenance operations inside the
machine, disconnect it from the mains and
set the all-pole switch to “0”.
6.1.2 Control panel
The control panel comprises a touch keypad and a display showing
messages during normal operation, programming and maintenance
phase.
The function of some buttons changes
according to the appliance phase (ordinary
dispensing or programming mode) change.
6.1.3 Button Description during Normal Operation
Press these buttons to dispense the programmed beverages or to
perform the required operations.
BUTTON BUTTON
A Selection button UP G
Large coffee
/ Ice
Americano
B
Selection button DOWN /
PowerSteam
O
Americano Jug
(1)
C
Pre-ground Coffee /
OK
(1)(2)
H macchiato (3)
D Menu P
Latte Macchiato
(3)
E Espresso I Cappuccino (3)
M Espresso x2 Q Caffè Latte (3)
F Coffee L Hot Milk (3)
N Coffee x2 R Hot Water (1)
(1) Button sequence described at chapter “Beverage Selection”
(2) Functions described at chapter “Ok Button”
(3)
Beverages with milk and coffee (any possible combination).
Please contact an authorised service centre to activate settings other than the default ones.
The machines are delivered with factory
standard settings.
