MAIN PARTS
Mod. LUXE / Mod. COFFEE / Mod. CAPPUCCINO / Mod. CAPPUCCINO USA / Mod. POWER STEAM / Mod. SELF
1 Left panel 15 Door
2 Cup shield 16 Coffee grounds drawer
3 Rear panel 17 Steam wand (except for COFFEE set-up)
4 Cup warming surface 18 Power button
5 Pre-ground coffee door (except for CAPPUCCINO USA set-up)
“I” Electrical functions enabled - Machine on - Indicator light on.
6 Right coffee bean hopper
“O” Electrical functions disabled - Machine off - “I” button indicator light off.
7 Right panel 19 Right grinder adjustment knob
8 Control panel 20 Right coffee grinder group
9 Rubber grip 21 Mechanical pulse counter
10 Hose clamp (CAPPUCCINO set-up)
It displays the number of beverages brewed by the machine.
11 Hot water wand (except for COFFEE set-up) 22 Brew group
12 Steam dispensing knob (except for COFFEE set-up) 23 Brew group cover
Clockwise:
Steam jet open
24 Milk froth adjustment (CAPPUCCINO set-up)
Counter-clockwise:
Steam jet closed
25 Temperature adjustment (CAPPUCCINO set-up)
13 Drip tray 26 Milk dispensing spout (CAPPUCCINO set-up)
14 Anti-scald steam wand rubber 27 Brew group
