Saeco Xsmall Plus - Fitting and Removing OETIKER Clamps

Saeco Int. Rev. 00 / Jul. 2008 Page 7 / 9
XSMALL 07 DISASSEMBLY
1) Boiler connection.
2) Other connections.
Replacing the hoses
1) Use a suitable pair of pliers to remove
the clamp (as illustrated).
2) Tighten the clamp as illustrated.
7.10. Fitting and removing OETIKER clamps
1
1
2
2
