Saeco Xsmall Plus - Technical Specifications; Machine Parameters and Performance

Saeco Int. Rev. 00 / Jul. 2008 Page 1 / 4
XSMALL 02 TECHNICAL SPECIFICATIONS
2.1. Technical specifi cations
2.2. Machine parameters and performance
Power supply and output: 230 V~ 50/60 Hz 1500 W - 120 V~ 60 Hz 1500 W - 100 V~
50/60 Hz 1300 W
Temperature monitoring: Variable resistor sensor (NTC) - transmits the value to the
electronic P.C.B.
Safety system: 2 manual reset or one-shot thermostats (175°C)
Coffee heat exchanger output:
Stainless steel
(230/120 V~) 1300 W - (100 V~) 1100 W
for coffee, hot water and steam dispensing
Gear motor: 33VC with 2 rotation directions; power supply 24VC
Pump: Ulka with reciprocating piston and 100°C cutout 48 W, 230 V, 50
Hz, Type EP5 approx. 13-15 bar 120 V, 60 Hz 100 V, 50/60 Hz
Overpressure valve: Opens at approx. 16-18 bar
Water fi lter: In tank
Coffee grinder: Direct current motor with fl at ceramic grinders
Hot water/steam valve Presblock
Automatic dosage Dose adjustment controlled by the electronic system
Power consumption: During the heating phase - approx. 5.6 A
Dimensions: W x H x D in mm: 295x325x420
Weight: 6.9 kg
Water tank capacity: 1.0 litres
Coffee container capacity 185 g coffee beans
Coffee dreg drawer capacity 08
Heat exchanger capacity: Approx. 10 cc
Water circuit fi lling time: Approx. 15 seconds for fi rst fi lling cycle
Heating time: Approx. 45 seconds
Dispensing temperature: Approx. 84 ± 4°C
Grinding time: Approx. 8-10 seconds
AMOUNT
OF PRODUCT
Minimum
amount
(Puls.)
Default
amount
(Puls.)
Maximum
amount
(Puls.)
Programm. by
the user
Programm. by
Production/Serv-
ice department
Espresso 70 165 600 Yes No
Medium coffee No No No No No
Large coffee 70 440 600 Yes No
Pre-ground No
Hot water
Continues until the water supply has been exhausted (fi ll circuit
status)
Steam for frother
Continues until the water supply has been exhausted (fi ll circuit
status)
Steam for Milk-
Island
No
