Page 8 / 9 Rev. 00 / Jul. 2008 Saeco Int.
07 DISASSEMBLY XSMALL
1) To remove the coffee grinder, simply
slide it out and remove its connections.
2) When replacing it, make sure the spring
(A) and the coffee pipe (B) are positioned
correctly.
7.11. Disassembling the coffee grinder
1
2
A
B
