Saftronics HPVFE - Drive Status and Fault Display; Drive Status Indicator (d006); Fault Code Display (d007-d009); Process Display Parameter (d010)

Display Group (continued)
Sailer Manual HPVFE
35
d006[Drive Status] Related Parameter(s): A434
Present operating condition of the drive.
Values
Default Read Only
Min/Max: 0/1
Display: 1
d007 [Fault 1 Code]
d008 [Fault 2 Code]
d009 [Fault 3 Code]
A code that represents a drive fault. The codes will appear in these parameters in the order they occur (d007 [Fault 1 Code] = the most recent
fault). Repetitive faults will only be recorded once.
Refer to Chapter 4 for fault code descriptions.
Values
Default Read Only
Min/Max: F2/F122
Display: F1
d010 [Process Display] Related Parameter(s): d001, A440, A438, A439
32 bit parameter.
The output frequency scaled by A440 (Process Factor) or by A438 (Process Time Lo) and A439 (Process Time Hi)
Output Freq x Process Factor = Process Display
Values
Default Read Only
Min/Max: 0.00/9999
Display: 0.01
