SAJ H2 Series Instruction Manual

4.3
Ground Connection
4.4
AC Grid Wire and
Backup Output
HYBRID SOLAR INVERTER INSTRUCTION MANUAL
Connection
Table4.1
Specications for Inteace
Figure 4.2
Inveer ground protection
Table 4.2
Recommended
Specications of AC Cables
Figure4.3
Thread the cables
Figure4.4
Procedure:
Connect the Cables
1.Open the waterproof cover, feed the AC cable through the AC waterproof hole.
2.Fix the cables according to conductor marks of L, N and PE.
Code
A
DC Switch
DC Input
DC Input
Batte Input
BMS/ CAN/ EMS/ METER/ DRM
CT/ Inveer Parallel po
4G/ Wi-Fi
Backup
Grid
Ground Connection
B
C
D
E
F
G
H
I
J
Name
1817
If the grid-connection distance is too far, please amplify diameter selection of the
AC cable as per the actual condition.
8~14 8
Additional grounding cable cross-sectional area (mm²): 8
Remove the screw on the ground terminal and secure the cable with a
screwdriver.
