SAJ H2 Series Instruction Manual

HYBRID SOLAR INVERTER INSTRUCTION MANUAL
2.3 Datasheet
2.2 Appearance
2.1 Packing list
Inveer
Handle
PV Plug Batte Plug Screw & expansion
bolt& washer
Figur
Dimensions of H2 series Product
07
13.6 16.7 18.2 22.7 27.3Max.Output Current [A]
Eciency
Max.Batte Charging/
Discharging Eciency
Max. Eciency
Euro Eciency
97.6%
97.0%
96.6%
Protection
AC Sho-circuit Protection Integrated
Overload Protection Integrated
Anti-islanding Protection Integrated(AFD)
AC Surge Protection Type II
DC Surge Protection Type II
AFCI Optional
Residual Current Mon-
itoring Unit
Batte Input Reverse
Polarity Protection
Integrated
Integrated
Inteace
Communication
PV Input
Batte
AC Output
Display
Communication Po
Wi-Fi/Ethernet/4G(Optional)/PLC(Optional)
CAN+RS485+DRM+CT+RS232
LED+LCD+APP(Bluetooth)
Plug-in connector
Quick Connector
MC4/H4
General Data
Noise [dBA]
Topology
Operating Temperature
Range
Cooling Method
Ambient Humidity
Altitude
<25
4000m(>3000m power derating)
0% ～ 100% Non-condensing
Natural Convection
-25°C to +60°C
Non-isolated
Mounting
Ingress Protection
Rear Panel
IP65
Weight [kg]
Dimensions[H*W*D] [mm]
17.6
󶀅499.0*385.5*193.5mm
Applicable Standard
Standard Warranty [Year]
CEI 0-21, VDE4105-AR-N, VDE0126-1-1, EN50438, G98, G99,
EN50549, AS4777.2,IEC62109-1&-2, EN61000-6-1/2/3/4
5 (standard)/10/15/20/25 (Optional)
Type
H2-3K-S2 H2-3.6K-S2 H2-4K-S2 H2-5K-S2 H2-6K-S2
PV String Input
Max. PV Array Power
[Wp]@STC
4500 5400 6000 7500 9000
Max. DC Voltage[V]
MPPT Voltage range [V]
550
90 - 500
Nominal DC Voltage[V]
360
Sta Voltage/Min. Input
100
Max. DC Input Current [A]
16/16
Number of MPPT 2
No. of Strings per MPPT 1 / 1
Batte Input
Rated Charging/
Discharging Power [W]
3000 3680 4000 5000 6000
Batte Type Lithium batte
Batte Voltage Range [V] 85 - 450
Max. Charging/Disch-
arging Current [A]
30 / 30
AC Output (On-grid)
3000 3680 4000 4999 6000
3000
3680 4000 4999 6000
Max. AC Current from
Utility Grid [A]
15.0 16.7 20.0 21.7 27.3
AC Output [Back-up Mode]
Grid Frequency/ Ran-
ge [Hz]
Nominal AC Voltage [V]
3000 3680 4000 4999 6000Max. Output Power [VA]
Total Harmonic Disto-
ion[THDi]
Power Factor [cos φ]
Rated Output Voltage [V]
100
55
55
50, 60
L/N/PE, 220, 230
< 3%（ at nominal power）
0.8 leading~0.8 lagging
230Vac，L/N/PE
Rated Output Frequen-
cy [Hz]
50/60
Output THDv (@ Liner
Load)
<3%
Max. AC Over Current
Protection[A]
Max. AC Fault Current[A]
Current Inrush[A]
Rated AC Power[W]
Max. AC Current
Output to Utility Grid [A]
Max. Sho Circuit Current
[A]
19.2/19.2
26.1 32.0 34.8 43.5 52.2
3600,60s 4416, 60s 4800, 60s 6000, 60s 7200, 60s
Peak Output Apparent
Power [VA]
Type H2-3K-S2 H2-3.6K-S2 H2-4K-S2 H2-5K-S2 H2-6K-S2
08
Rated Apparent
power[VA]
Communication
module （Optional）
3300
3680 4400 4999 6000
Max. Apparent
power[VA]
Voltage[V]
Rated/
