SAJ H2 Series Instruction Manual

5.
DEBUGGING
Figure 5.1
LED indicators
3029
HYBRID SOLAR INVERTER INSTRUCTION MANUAL
5.1 Sta Up and Shut Down Inveer
5.1.1 Start Up
5.1.2 Shut Down
(1)Connect the AC circuit breaker
(2)Connect the DC circuit breaker between inveer and batte(if applicable)
(3)Turn ON the batte(if applicable)
(4)Turn ON the DC switch on the inveer
(5)Install the communication module into the inveer
(6)Setup the initial setting for inveer on eSAJ Home
(7)Obsee the LED indicators on the inveer to ensure the inveer is running properly
Automatically shut down, when the solar light intensity is not strong enough during sunrise
andsunset or the output voltage of photovoltaic system is less than the minimum input power
of inveer, inveer will shut down automatically.
5.2 Introduction of
LED Indicator
Shut down manually, disconnect AC side circuit breaker rst, if multiple inveers are connected,
disconnect the minor circuit breaker prior to disconnection of main circuit breaker. Disconnect
the DC switch after inveer has repoed grid connection lost alarm.
