62 Fan Coil FC600 Instruction Manual
The FC600 Fan Coil requires no special maintenance. Periodically, the outer casing can be wiped clean using
a dry cloth (please DO NOT use solvents, polishes, detergents or abrasive cleaners, as these can damage the
thermostat). There are no user serviceable parts within the unit; any servicing or repairs could only be carried
out by Salus Controls or their appointed agents.
4.12 Technical Info
Product Specication
Model: FC600
AC power supply 230Vac +10% -15% 50Hz
Temperature Sensing specifications
Temperature Sensors Air sensor ( indoor ) + External-sensor (optional)
Unit of temperature measurement °C
Indoor temp sensor measuring range 0°C –45°C
Indoor temp sensor display range 0°C –45°C
Indoor temp display resolution 0.5°C or 0.1°C (selectable)
Indoor temp set point range 5°C - 40°C
Indoor Temperature accuracy offset range From -3,0 to +3,0 in 0,5 steps
Frost protection point Yes
Overheat protection Yes
Temperature sampling duration Every 15 seconds
Multifunctional input S1-M/S2-M
Temperature sensor input Type NTC 10 kOhm B 25/50 = 3950K, R 25 = 10.000KOhm
Temperature range 0…50°C
Clock display format 12 / 24 hour format
Program Setting
Program 5+2 / 7 individual days / all 7 days same
Temporary & Permanent Override Yes
Memory
Non-volatile memory MCU flash store clock and all user settings
Backup power during power blackout Uhe ideal position to locate the RT310 thermostat is about
1.5m above floor level, in a location where the thermostat
is accessible, reasonably lit and free from extremes of tem-
perature and draughts. Do not mount the thermostat on an
outside wall, above a radiator or in a location where it may be
subjected to direct sunlight.p to 17hrs
Dust and water proof level IP30
Operating environment
Operating temperature 0°C - 50°C
Storage temperature -25°C - 60°C
Relative humidity ( non-condensed ) <95% r.h.
4.11 Cleaning and Maintenance
