Sam4s ER-925 - PC Communications

15
PC Communications
 The ER-900 PC Utility provides the option to upload and download program files.
 The graphics logo can be designed on a PC and transmitted to the register using the utility
 It is also possible to upload the register X1, Z1, and X2, Z2 reports to the PC.
Baud Setting
S-MODE
?
SBTL
8
1
QTY/Time
0
CASH
Parity Port Setting
S-MODE
?
SBTL
8
2
QTY/Time
0
CASH
Data Bits Port Setting
S-MODE
?
SBTL
8
3
QTY/Time
0
CASH
Stop Bits Port Setting
S-MODE
?
SBTL
8
4
QTY/Time
0
CASH
Device Function Port Settings
S-MODE
?
SBTL
8
5
QTY/Time
1
CASH
Sets the port to connect to a PC
80 = Serial Port 1 82 = RJ45 Port 3
81 = Serial Port 2 83 = USB / RJPort 4
80 = Serial Port 1 82 = RJ Port 3
81 = Serial Port 2 83 = RJ Port 4 / USB Port
80 = Serial Port 1 82 = RJ Port 3
81 = Serial Port 2 83 = RJ Port 4 / USB Port
80 = Serial Port 1 82 = RJ Port 3
81 = Serial Port 2 83 = RJ Port 4 / USB Port
80 = Serial Port 1 82 = RJ Port 3
81 = Serial Port 2 83 = RJ Port 4 / USB Port
