Wiring Diagrams
TO SAMSUNG POLE
DISPLAY
ECR POLE
3 RED
5 BLUE
9 WHITE
4
8
TO METROLOGIC SCANNER
ECR SCAN
2 GREEN
5 BROWN
9 ORANGE
Sam4s to PC Cable
ECR 9M 9M PC
2 3
3 2
4 6
6 4
5 5
7 8
8 7
TO PRINTER Cable
ECR 9M 25M PRINTER
3 3
2 2
6 20
8
4 6
5 7
