19
METROLOGIC MS7120 (ORBIT) CONFIGURATION FOR SAM4S
Scan the following barcodes in sequence to setup the scanner. If an error occurs, turn the scanner off and on.
1
ENTER CONFIG MODE
6
ENABLE UPC PREFIX
2
RECALL DEFAULTS
7
8 DATA BITS
3
DISABLE LF SUFFIX
8
9600 BAUD RATE
4
ODD PARITY
9
EXIT CONFIG MODE
5
ENABLE RS-232 MODE
