Update Boot Area
The relevant update instructions supplied with the .bin file will tell whether both Boot
Area and/or Application Area updates are required, mostly it will be application.
1. Connect the Serial Cable From ECR to PC.
2. At the register, turn the control lock to the S position.
3. Turn the power switch to the OFF position.
4. Press and hold the CASH and CLERK keys.
Note Use the keys in their default locations, the upper-right and lower-
right keys on the keyboard.
5. While continuing to hold the CASH and CLERK keys, turn the power
switch to the ON position. The display will illuminate and the error
tone will sound beep-beep-beep in quick succession; Release the keys.
6. At the PC, execute the program “NEWNET_DOWN.exe”.
The Download dialog box displays.
7. Select the appropriate com port connection at your PC at the PORT#
option buttons.
8. Click SEL. find the folder where the update files are located and select
NEWNET.bin.
9. Select Boot Area Only option button.
10. Press OK Button. The download takes about 30 seconds; the scroll bar
will track the progress of the download.
At the ECR, the display will flash slowly while the update is taking place.
11. At the PC, the message Completed displays. Click OK and the
Download program will close.
12. At the ECR, the display will flash rapidly, indicating the update is
complete, Turn the power switch to the OFF position.
