8
Gcube Series Receipt Printer
You need the appropriate interface cable.
1. Plug the cable connector securely into the printer’s interface connector.
2. Tighten the screws on both sides of the cable connector.
3. Attach the other end of the cable to the host device.
1.3. Connecting the host device
WARNING : Use a drawer that matches the printer specification.
Using an improper drawer may damage the drawer as well as the printer.
CAUTION : Do not connect a telephone line to the drawer kick-out connector;
otherwise the printer and the telephone line may be damaged.
Plug the drawer cable into the drawer kick out connector on the back of
the printer next to the power supply connector.
To use the drawer, you can
connect the cable to the
connector.
1.4. Connecting the Drawer
