13
B.2 Electric bilge pumps:
Electric bilge pumps are controlled via the SCHEIBER panel (see below under 'SCHEIBER CONTROL PANEL').
The electric bilge pumps are triggered automatically. Operation can be forced via the SCHEIBER control panel.
The system is equipped with a visual and audible alarm located on the control panel.
See drawing DDF PBL 061 009 for details of the installation.
In each hull:
• 1 pump under the aft cabin bathroom.
• 1 pump at the front of the engine compartment.
The bilge pumps are powered even if the SERVICE
battery switch is not engaged.
24V Bilge pump
IV- SAFETY
