45
A1 - Converter/Charger combination (Chart table)
Power rating: 70 Ah/3000 W (STD) or 120 Ah/5000 W (optional) - Voltage: 24V/230V
The charger is powered either from the shore (230V - 50 or 60 Hz) or from the generator
A2 - Converter (refrigerators and freezers) - (Starboard technical compartment)
Power rating: 1600 W - Voltage: 24V/230V
Is powered by the battery bank.
200 V power supply for refrigerators, freezers, wine cellar, ice maker, water fountain.
VII – ALTERNATING CURRENT CIRCUIT – SWITCHING ON
A - Converter and charger
