B.1 - Fresh water system (fed from the fresh water pump)
The freshwater tank with a capacity of 1,150 L is located under the saloon floor (port side).
The 24V 45-litre freshwater pump is located in the aft port technical compartment
See drawing DDF PIE 061 028 for details of the tank
Open the ¼ turn valve on the tank
The freshwater pump supplies the following equipment:
all bathrooms, galley mixer tap, all toilets except skipper cabin toilet, cockpit shower, dishwasher, water heaters.
The tank is filled via the filler on the starboard side of the cockpit
During filling, monitor the level on the control panel
B– WATER SYSTEMS:
XI - COMFORT
