Index revision : C - November 2017 21 7030
3.2. Operating characteristics
* Resistivity values measured with Resistivohmeter AP 1000 (SAMES P/N: 910005790). For lower
values, contact SAMES KREMLIN.
For values greater than 6 MΩ.cm, you are advised to use the PPH 308 with integrated high
voltage unit.
** m
0
3
values given for a temperature of 20 °C at 1013 mbar atmospheric pressure.
Weight
PPH 308 without hoses or cables 2.5 kg
Current
Maximum operating voltage 100 kV
Maximum operating current 200 μA
Speed
Recommended rotation speed 10,000 to 45,000 rpm
Paint
Paint flow rate
30 to 500 cc/min max. (depending on
paint)
Normal supply pressure 6 to 8 bar
Maximum pressure 10 bar max.
Viscosity 12 to 40 seconds - FORD cup # 4
Viscosity 12 to 45 seconds - AFNOR cup # 4
Paint resistivity ρ ≥ 0,5 MΩ.cm *
Air pressure
Microvalve pilot 6 to 10 bar max.
Bearing air 6 to 7 bar max.
Microphone air 1.9 to 3 bar constant
Shaping air 6 bar maximum
Compressed Air quality
Filtered (bearing air), dry, oil and dust-free according to standard NF ISO 8573-1
Maximum dew point at 6 bar (87psi) Class 4, i.e + 3° C (37° F)
Maximum oil concentration
Class 4, i.e 2 mg / m
0
3 **
Maximum particle size of solid con-
taminants
Class 3, i.e 5 μm
Maximum concentration of solid con-
taminants
5 mg /m
0
3 **
Air consumption
Pilot 10 Nl/min
Bearing air 125 Nl/min
Shaping air
0 to 600 Nl/min according to the shap-
ing air assembly used
Turbine see RT Nr 6350
