SAMES KREMLIN PPH 308 - 1 Health and Safety Instructions; Configuration of Certified Equipment; Markings on Atomizer

Index revision : C - November 2017 6 7030
1. Health and Safety Instructions
This manual contains links to the user manuals for the following:
• see RT Nr 6285 for magnetic bell cups,
• see RT Nr 6350 for the “Magnetic bell cup” type magnetic air turbine.
• see RT Nr 6021 for the microvalve
• see RT Nr 6190 for the microphone,
• see RT Nr 7010 high-voltage unit UHT 188 EEx e.
• see RT Nr 6213 GNM200 control module user manual,
• see RT Nr 6364 for the electrical systems user manual,
1.1. Configuration of certified equipment
These user manuals define the configuration of certified equipment.
1.2. Markings on atomizer
SAMES KREMLIN Meylan France
CE 0080
PPH
P/N: *
ISSeP06ATEX032X**
II 2 G
EEx > 350mJ
(Serial no.)
* ATEX PPH 308 configurations
** 'X' indicates that the safety distance specified in this manual (between the HV components
of the atomizer and all grounded parts) must be observed to ensure safe operation of the
equipment.
Atomizer - P/N 910003350 Microvalves - P/N 1507375 Turbine - P/N 910000295 High-voltage unit UHT 188 EEx e -
P/N 910001759
P/N without HV cable Note: refer to health and safety instructions for maximum lengths of electrical capacities
P/N PPH
(*)
GNM 200A
P/N 1517071
X X 910003721 X
