Index revision : C - November 2017 26 7030
4.6. Compensation air diagram
25 : The compensation air prevents any
contamination of the inner shaping air shroud
and is controlled via a remote regulator.
4.7. Turbine exhaust diagram
25
Compensation air - Dia. 6 x 8 - Poly-
amide
421
Turbine exhaust - Dia. 8 x 10 -
Polyamide
