Index revision : C - November 2017 33 7030
6. Atomizer Maintenance
WARNING : These operations are to be performed only by trained persons.
6.1. Removing and re-installing the PPH 308
6.1.1. Disassembly
Rinse the PPH 308 before disassembly.
• Switch off the high-voltage power supply.
• Unlock the cover with the special tool (P/N 1308689).
• Unscrew and remove the cover.
• Loosen the screw that lock the placebo into its sheath (see § 2 page 17).
• Disconnect all hoses entering the Manifold block and 1 PV block (except hoses
connected between the 1 PV block and Manifold block).
• Loosen the 4 screws securing PPH 308 to holder.
WARNING : Do not remove the clamps from the MANIFOLD block to make sure they are not lost.
6.1.2. Reassembly
• Secure PPH 308 to support with the 4 screws.
• Reconnect all hoses to the MANIFOLD block and 1 PV block.
• Manually refit the cover and lock with the special tool (P/N 1308689).
6.2. Bell cups
For assembly and disassembly instructions see RT Nr 6285
6.3. Shaping air assembly (shroud and cover)
For assembly and disassembly instructions for the shaping air assembly see RT Nr 6285
6.4. Turbine
see RT Nr 6350 see attached manual.
