Index revision : C - November 2017 50 7030

8.5.2. To connect two PPH 308 atomizers to a single HVU (optional)

Item Part number Description Qty

Unit of

sale

First

priority

Wear

910003563 Placebo and resistor 1 1 X

1 U1CBBR057

Protective hose for HV cable, D:10/12

clear polyamide

4.25

m - -

2 E2DAVD101 High voltage cable (100kV)

4.25

m - -

3 E4CSHT181 HV cable screw-on end-fitting 1 1 - -

4 F6RXZG085 Stainless steel clamp and seal 1 1 - -

5 1315058 Clamp nut 1 1 - -

6 1411689 Split cone 1 1 - -

7 900002154 Cable-securing adapter 1 1 - -

8 548304 HV cable stopper 1 1 - -

9 548303 HV contact disc 1 1 - -

Q2HRDC095

Spring 1 1 - -

11 900002471 HV contact housing 1 1 - -

12 200000004 Spring 2 1 - -

13 1315102 22 Mohm Resistor 1 1 X

14 J2FTDF416 O-ring - Viton 1 1 X
