SAMES KREMLIN PPH 308 - Colour Change and Rinsing Cycles

Index revision : C - November 2017 27 7030
4.8. Colour change and rinsing cycles
Example of atomizer integration
• Standard conditions: 6 bar, air, solvent and paint.
• Colour change block and rinsing block operated 1 to 1.5 metres away from atomizer.
PV31PV31
PV32PV32
PV11PV11
DES03335
11
41
32
31
PV41PV41
Air PV - bell cup
Solvent PV - bell cup
Solvent PV - injector rinsing
Colour change
block
Air PV
Solvent PV
Colours
Flow-rate adjustment restrictor (250 cc/min)
Flow-rate adjustment restrictor (300 cc/min)
Air PV - injector rinsing
0
1 2
3
4
5
6
DES01056
Air PV - Colour
change block
Solvent PV - Colour
change block
Seconds
Rinsing supply circuit only
Dump valve
PV 41
