Index revision : C - November 2017 28 7030
• Normal paint flow rate with valve activated: 150 cc/min
• X: Time required for the paint to flow from the colour change block to the bell cup.
• Y: Time required for paint to leave the bell cup.
• Recommended solvent flow rate for injector: 300 cc/min
• Recommended solvent flow rate for bell cup rinsing: 250 cc/min
• Always use restrictors if the flow rate exceeds the values above.
• The final pneumatic pulse clears and dries the rinsing circuit for the outside of the bell cup
in order to prevent any solvent being sprayed.
