9.1 DISTINTA BASE HCV
9.1 HCV PART LIST
35
55 GUARN OR-3225 2.62x56.82 (2-140) SEAL OR-3225 2.62x56.82 (2-140) 2
56 GUARN OR-2350 1.78x88.62 (2-43) SEAL OR-2350 1.78x88.62 (2-43) 1
57 GUARN OR-3087 2.62x21.89 (2-118) SEAL OR-3087 2.62x21.89 (2-118) 4
58 GUARN OR-3137 2.62x34.59 (2-126) SEAL OR-3137 2.62x34.59 (2-126) 1
59 GUARN OR 3081 2.62x20.29 (2-117) SEAL OR 3081 2.62x20.29 (2-117) 2
60 DADO ES.AUTOBLOCC. M10x1.5 UNI 7473-6S SELF-LOCKING NUT M10x1.5 UNI 7473-6S 1
61 DADO ESAG. M10X8 UNI/5588-65/6S HEX. NUT M10X8 UNI/5588-65/6S 2
62 DADO ESAG. M6X5 UNI/5588-65/6S HEX. NUT M6X5 UNI/5588-65/6S 1
63 TAPPO AD ESPANSIONE MB/800-060 (D = 6) EXPANDER PLUG MB/800-060 (D = 6) 2
64 SPINA UNI 2338-B-6x10-St PIN UNI 2338-B-6x10-St 6
65 SPINA UNI-ISO 2338-B-8x20-St PIN UNI-ISO 2338-B-8x20-St 2
66 SPINA UNI-ISO 2338-B-8x15-St PIN UNI-ISO 2338-B-8x15-St 2
67 RONDELLA DI SICUREZZA ZIGRINATA Di=8.4 SPRING WASHER Di=8.4 4
68 VITE TCEI UNI 5931 M8x40-8.8 S.H. SCREW UNI 5931 M8x40-8.8 6
68 VITE TCEI UNI 5931 M8x50-8.8 S.H. SCREW UNI 5931 M8x50-8.8 6 HNA 95
69 VITE TCEI UNI 5931 M6x16 12.9 S.H. SCREW UNI 5931 M6x16 12.9 6
70 VITE TE UNI 5739 M8x12-8.8 HEX. H. SCREW UNI 5739 M8x12-8.8 4
71 VITE TE UNI 5739 M8x25-8.8 HEX. H. SCREW UNI 5739 M8x25-8.8 4
72 ROSETTA UNI 6592 8.4x17 R80 WASHER UNI 6592 8.4x17 R80 4
73 VITE STEI UNI 5927 M6x25 P.CONICA GRUB SCREW UNI 5927 M6x25 TAPERED H. 1
74 VITE STEI UNI 5925 M10x25 P.CILINDRICA GRUB SCREW UNI 5925 M10x25 CYLINDRICAL H. 1
75 VITE TCEI UNI 5931 M8x20-12.9 S.H. SCREW UNI 5931 M8x20-12.9 22
76 ROND. RAME RIC. 0=13.3x19x1.5 (1/4" GAS) SOFT COPPER WASHER D=13.3x19x1.5 (G 1/4") 6
77 BULLONE RACCORDO 1/4"G HCV NUT x STUD ADAPTOR 1/4"G HCV 1
77 RACCORDO STROZZATORE G1/4" HCV HNA95 STUD ADAPTOR G1/4" HCV HNA95 1 HNA 95
78 TUBO DI COLLEG. HCV PIPE HCV 1
79 TAPPO TE G 3/4 MAGNETICO MAGNETIC PLUG TE G 3/4 1
80 ROSETTA DI TENUTA GM 2000 M10 SEALING WASHER GM 2000 M10 2
81 ROND. RAME RIC. 0= 26.7x33x1.5 (3/4" GAS) SOFT COPPER WASHER 0= 26.7x33x1.5 (3/4" GAS) 2
82 TAPPO TCEI G.1/4 -DIN 908- S.H. PLUG G.1/4 -DIN 908- 4
83 VITE TCEI UNI 5931 M16x45-12.9 S.H. SCREW UNI 5931 M16x45-12.9 2
84 VITE TCEI UNI 5931 M16x70-8.8 S.H. SCREW UNI 5931 M16x70-8.8 2
85 TAPPO TCEI G 3/4 DIN 908 S.H. PLUG G 3/4 DIN 908 1
86 LINGUETTA A 6x6x20 UNI 6604-69 KEY A 6x6x20 UNI 6604-69 1
87 SOTTOTAPPO D = 26 (1"SAE) PLASTIC PLUG D = 26 (1"SAE) 2
88 SOTTOTAPPO D = 32 (1"GAS) PLASTIC PLUG D = 32 (1"GAS) 1
89 TARGHETTA ROTAZIONE ROTATION PLATE 1
90 TARGHETTA RICON. MOT.BGM/MOT. E POMPE HMT MOTOR DATA PLATE BGM/MOT. / PUMP HMT 1
91 CHIODO 1.9X5 UNI 52 RIVET 1.9X5 UNI 52 4
92 DISTANZIALE x BUSSOLA VALV. DI MAX. HCV SPACER xBUSHING PRESS. RELIEF VALVE HCV 2
93 BUSSOLA PER VALVOLA DI MASSIMA HCV BUSHING x PRESSURE RELIEF VALVE 2
94 MOLLA x VALV.DI MAX. HCV SPRING x PRESSURE RELIEF VALVE HCV 2
95 VITE STEI UNI 5927 M5x12 P.CONICA GRUB SCREW UNI 5927 M5x12 TAPERED H. 1
96 ANELLO BIMETALLICO PER BARILETTO HCV BIMETALLIC RING x CYL. BARREL HCV 1
97 SPINA EL. UNI-ISO 8750-5x16-St SPIROL SPRING PIN UNI-ISO 8750-5x16-St SPIROL 2
98 TAPPO PE ROSSO 3/4"GAS FIL. 05TF PLASTIC PLUG G 3/4" 1
99 ROND. RAME RIC. D=10.2x16x1.5 (1/8"GAS) SOFT COPPER WASHER D=10.2x16x1.5 (G 1/8") 2
100 BULLONE RACCORDO 1/8"G HCV NUT x STUD ADAPTOR 1/8"G HCV 2
101 ANELLO EL.x ALB. D=35 CIRCLIP FOR SHAFT D=35
N DENOMINAZIONE ITEM Q. NOTE
