samhydraulik HCV - 9.7 HE Control Part List

9.7 DISTINTA REGOLATORE HE
9.7 HE CONTROL PART LIST
42
1 TIRANTE PER COMANDO HI HCV PULL ROD FOR HI CONTROL HCV 2
1
TIRANTE X COMANDO HI HCV HCV HE CONTROL PULL ROD 2
2
BUSSOLA PER COMANDO HE HCV HCV HE CONTROL BUSHING 2
3
VTCCE 8.8 M8x50 FORATA x HE HCV HE SOCKET HEAD SCREW M8x50 WITH HOLE 4
4
GUARNIZIONE X ELETTROMAGNETE SEAL FOR SOLENOID 4
5
GUARNIZIONE PILOTAGGIO HCV HCV PILOT SEAL 1
6
VITE TE UNI 5739 M6x25 - 8.8 SOCKET HEAD SCREW M6x25 2
7
PERNO PER COMANDO HE HCV HCV HE CONTROL PIVOT 1
8
MOLLA COMANDO HE HCV HCV HE CONTROL SPRING 2
9
MOLLA X COMANDO HE HCV HCV HE CONTROL SPRING 2
10
CAPPELLOTTO x COMANDO HE HCV HCV HE CONTROL CAP 1
11
PISTONE X PILOTAGGIO HI HCV HCV HE CONTROL PILOTING PISTON 1
12
ASTA PER COMANDO HE HCV HCV HE CONTROL ROD 2
13
COLONNETTA COR. 1/8 G CH. 14 SHORT PIPE G 1/8î KEY 14 1
14
CASSETTO X PILOTAGGIO HCV HCV PILOTING SPOOL 1
15
CASSETTO PER COMANDO HE HCV HCV HE CONTROL SPOOL 2
16
INTERFACCIA DX PER COMANDO HE HCV HCV HE CONTROL RIGHT INTERFACE 1
17
INTERFACCIA SX PER COMANDO HE HCV HCV HE CONTROL LEFT INTERFACE 1
18
PILOTA PER COMANDO HI/HE HCV HCV HI / HE CONTROL PILOT 1
19
TAPPO x HCV PLUG FOR HCV 1
20
GUIDA-MOLLA PER COMANDO HE HCV HE CONTROL SPRING GUIDE 4
21
DISTANZIALE PER ELETTROMAGNETE SPACER FOR SOLENOID 2
22
PERNO FILETTATO HCV THREADED PIVOT HCV 1
23
PERNO FILETTATO HCV THREADED PIVOT HCV 1
24
ANELLO ELASTICO X FORO D=32 UNI7437-32 CIRCLIP FOR HOLE D = 32 1
25
GUARN OR-2043 1.78x10.82 (2-13) O-RING 2-013 2
26
GUARN OR-2018 1.78x4.48 (2-8) O-RING 2-008 1
27
GUARN OR-2031 1.78x7.65 (2-11) O-RING 2-011 4
28
GUARN OR-2050 1.78x12.42 (2-14) O-RING 2-014 2
29
GUARN OR-2112 1.78x28.30 (2-24) O-RING 2-024 1
30
GUARN OR-3068 2.62x17.12 (2-115) O-RING 2-115 4
31
VITE TCEI UNI 5931 M5x60-8.8 SOCKET HEAD SCREW M5x60 8
32
VITE TCEI UNI 5931 M6x55-8.8 SOCKET HEAD SCREW M6x55 4
33
VITE STEI UNI 5923 M6x8 P.PIANA GRUB SCREW M6x8 PLANE HEAD 1
34
DADO M6 UNI 5589 NUT M6 2
35
DADO ESAG. AUTOBL. M5X0.8 UNI 7473 SELF LOCKING NUT M5x0.8 2
36
ROSETTA EL. UNI 8842-A6 HCV SPRING WASHER M6 1
37
ROND. RAME RIC. 0=10.2x16x1.5 (1/8"GAS) SOFT COPPER WASHER G 1/8î 1
38
ROND. RAME RIC. 0=13.3x19x1.5 (1/4" GAS) SOFT COPPER WASHER G 1/4î 2
39
ROSETTA DI TENUTA GM 2000 M6 SEALING WASHER GM 2000 M6 2
40
ROSETTA DI TENUTA GM 1500 M8 SEALING WASHER GM 1500 M8 4
41
ROSETTA DI TENUTA GM 1500 M12 SEALING WASHER GM 1500 M12 1
42
TAPPO TCEI G.1/4 (DIN 908)-8.8 SOCKET HEAD PLUG G 1/4î 2
43
TAPPO AD ESPANSIONE MB/800-050 (D=5) EXPANDER PLUG D = 5 11
44
ELETTROMAGNETE PROPORZIONALE (12 V OPPURE 24 V) PROPORTIONAL SOLENOID (12VDC OR 24 VDC) 2
45
SPINA UNI 2338-B-6x10-St PIN 6x10 2
N DENOMINAZIONE ITEM Q. NOTE
