9.11 DISTINTA REGOLATORE HE+HI
9.11 HE+HI CONTROL PART LIST
48
1
TIRANTE x COMANDO HI HCV
HCV HI CONTROL PULL ROD 2
2
BUSSOLA x COMANDO HE HCV
HCV HE CONTROL BUSHING 2
3
VITE M8x50-8.8 FORATA x HE
SCREW M8x50-9.8 WITH HOLE x HE 4
4
GUARNIZIONE x ELETTROMAGNETE
SOLENOID SEAL 4
5
GUARNIZIONE PILOTAGGIO HCV
SEAL FOR PILOTING 1
6
VITE T.C.E.I. UNI 5737 M6x25-8.8
SOCKET HEAD SCREW M6x25-8.8 2
7
TAPPO PER COMANDO HE HCV
HCV HE CONTROL PLUG 1
8
MOLLA PER COMANDO HE HCV
HCV HE CONTROL SPRING 2
9
MOLLA PER COMANDO HE HCV
HCV HE CONTROL SPRING 2
10
CAPPELLOTTO PER COMANDO HE HCV
HCV HE CONTROL CAP 1
11
PISTONE PER PILOTAGGIO HI HCV
HCV HE CONTROL PILOTING PISTON 1
12
ASTA PER COMANDO HE HCV
HCV HE CONTROL ROD 2
13
COLONNETTA CORTA G 1/8" M - G 1/8" F
SHORT PIPE G 1/8" M - G 1/8" F 1
14
CASSETTO PER PILOTAGGIO HCV
HCV HE CONTROL PILOTING SPOOL 1
15
CASSETTO PER COMANDO HE HCV
HCV HE CONTROL SPOOL 2
16
INTERFACCIA DESTRO PER COMANDO HE HCV
HCV HE CONTROL PLUG RIGHT INTERFACE 1
17
INTERFACCIA SINISTRO PER COMANDO HE HCV
HCV HE CONTROL LEFT INTERFACE 1
18
PILOTA PER COMANDO HI/HE HCV
HCV HI/HE CONTROL PILOT 1
19
TAPPO PER HCV
HCV PLUG 1
20
GUIDAMOLLA PER COMANDO HE HCV
HCV HE CONTROL SPRING GUIDE 4
21
DISTANZIALE PER ELETTROMAGNETE
SOLENOID SPACER 2
22
PERNO FILETTATO ( SFERA D = 10 )
THREADED PIVOT (BALL D = 10) 1
23
PERNO FILETTATO ( SFERA D = 8 )
THREADED PIVOT (BALL D = 8) 1
24
ANELLO ELASTICO PER FORO D = 32 UNI 7437-32
CIRCLIP FOR HOLE D = 32 1
25
ANELLO O-RING 2-013 (A+P 2043)
O-RING 2-013 2
26
ANELLO O-RING 2-008 (A+P 2018)
O-RING 2-008 1
27
ANELLO O-RING 2-011 (A+P 2031)
O-RING 2-011 4
28
ANELLO O-RING 2-014 (A+P 2050)
O-RING 2-014 2
29
ANELLO O-RING 2-024 (A+P 2112)
O-RING 2-024 1
30
ANELLO O-RING 2-115 (A+P 3068)
O-RING 2-115 4
31
VITE T.C.C.E. UNI5931 M5x60 - (8.8)
SOCKET HEAD SCREW M5x60-8.8 8
32
VITE T.C.C.E. UNI 5931 M6x55 - (8.8)
SOCKET HEAD SCREW M6x55-8.8 4
33
VITE S.T.E.I. UNI 5923 M6x8 P. PIANA
GRUB SCREW M6x8 PLANE HEAD 1
34
DADO ESAG.BASSO M6 UNI 5589-65/6S
HEX. NUT M6/6S 2
35
DADO AUTOBLOCCANTE M5x0.8 UNI 7473
SELF LOCKING NUT M5x0.8 2
36
ROSETTA ELASTICA D = 6 UNI 8842 A
SPRING WASHER D = 6 1
37
RONDELLA IN RAME G 1/8"
SOFT COPPER WASHER G 1/8" 1
38
RONDELLA IN RAME G 1/4"
SOFT COPPER WASHER G 1/4" 2
39
RONDELLA DI TENUTA KSA - GM2000 M6
SEALING WASHER GM 2000 M6 2
40
RONDELLA DI TENUTA KSA - GM1500 M8
SEALING WASHER GM 1500 M8 4
41
RONDELLA DI TENUTA KSA - GM1500 M12
SEALING WASHER GM 1500 M12 1
42
TAPPO PE ROSSO G 1/4"
PLASTIC PLUG G 1/4" 2
43
TAPPO AD ESPANSIONE MB800-050
EXPANDER PLUG D = 5 11
44
ELETTROMAGNETE PROPORZIONALE (12 V OPPURE 24 V)
PROPORTIONAL SOLENOID (12 V OR 24 V DC) 2
45
SPINA UNI 2338-B- 6x10-St
PIN 6x10 2
46
PROLUNGA PORTA VALVOLA M/F G 1/4"
VALVE SUPPORT G 1/4î 2
47
VALVOLA UNIDIREZIONALE A CARTUCCIA G 1/4"
G 1/4" CARTRIDGE CHECK VALVE 2
N DENOMINAZIONE ITEM Q. NOTE
