Samson 3730-1 User Manual

EB 8384-1 EN 11
Markings on the device
2 Markings on the device
2.1 Nameplate
1 Supply pressure
2 Type of protection for explosion-
protected devices
3 Signal range
4 Firmware version
5 Model no.
6 CongurationID
7 Serial number
8 Compliance
Explosion-protected version Version without explosion protection
* See technical data and explosion-protection
2
SAMSON
Supply
Input
Positioner
SAMSON AG D-60314 Frankfurt Made in Germany
Firmware
Model 3730 - 1
Var.-ID Serial no.
3
4
6
7
5
1
8
3730 - 1
certificate for permissible ambient temperature
and maximum values for connection to
certified intrinsically safe circuits.
Limit switches, software*
Limit switch, inductive
SAMSON 3730 - 1
8
Supply
Positioner
1
Input
3
Limit switch, inductive
Limit switches, software
See technical data for ambient temperature
Firmware
4
Model 3730 - 10
5
Var.-ID Serial no.
6
7
SAMSON AG D-60314 Frankfurt Made in Germany

Samson 3730-1 Specifications

General

Supply air pressure	1.4 to 7 bar (20 to 100 psi)
Housing material	Aluminum
Protection class	IP 65
Output Signal	Pneumatic
Pressure Range	Up to 7 bar (100 psi)
Port Size	G1/4 or 1/4" NPT
Material	Aluminum
Accuracy	±1% of span
