EB 8355-2 EN 9-5
Servicing
1 2 23
4
5
6789
1 Label
2 Screw
3 Cover with rubber seal
4 Terminal block
5 Plate
6 Solenoid valve
7 Screw
8 Seals
9 Metal plate
Fig.9-2: Installing the limit switches and solenoid valve
