Product Specifications
Samsung Electronics 2-17
Indoor Unit(cont.)
QMini 4 way cassette
Model AVXCMH028E6 AVXCMH036E6 AVXCMH056E6 AVXCMH060E6
Power Supply ø/V/Hz 1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50
Mode*
1)
HP / HR HP / HR HP / HR HP / HR
Performance
Capacity
Cooling*
2)
kW 2.8 3.6 5.6 6.0
Btu/h 9,500 12,200 19,100 20,400
Heating*
3)
kW 3.2 4.0 6.3 6.8
Btu/h 10,900 13,600 21,400 23,200
Condensate (with High fan speed) Liters/h 1.28 1.75 2.23 2.39
Power
Input W 90 90 95 100
Running Current A 0.5 0.5 0.52 0.55
Sound Level Sound Pressure (High/Low)*
4)
dB(A) 30 / 25 34 / 27 41 / 33 41 / 33
Fan
Type - Turbo Fan Turbo Fan Turbo Fan Turbo Fan
Motor
Model - ASS035AUEA ASS035AUEA ASS035AUEA ASS035AUEA
Type - Non Feedback SSR Non Feedback SSR Non Feedback SSR Non Feedback SSR
Output W *5) *5) *5) *5)
Airflow Rate
Cooling (High) m
3
/min 10.1 10.1 10.6 12.2
Heating (High) m
3
/min 11.9 11.9 12.6 14.5
Refrigerant
Type - R410A R410A R410A R410A
Control Method - EEV EEV EEV EEV
Temperature Control - Micom & Thermistors Micom & Thermistors Micom & Thermistors Micom & Thermistors
Safety Devices - Fuse Fuse Fuse Fuse
Piping
Connections
Liquid (Flare) ø, mm 6.35 6.35 6.35 6.35
Gas (Flare) ø, mm 12.7 12.7 12.7 12.7
Drain (Quick Lock) ø, mm VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25)
Weight
Net Weight kg 17.0 17.0 17.0 17.0
Shipping Weight kg 20.0 20.0 20.0 20.0
Dimensions
Net Dimensions (W x H x D) mm 575x260x575 575x260x575 575x260x575 575x260x575
Shipping Dimensions (W x H x D) mm 660x310x635 660x310x635 660x310x635 660x310x635
Panel Size
Model - PMSMA PMSMA PMSMA PMSMA
Net Weight kg 3.5 3.5 3.5 3.5
Shipping Weight kg 6.2 6.2 6.2 6.2
Net Dimensions (W x H x D) mm 670x35x670 670x35x670 670x35x670 670x35x670
Shipping Dimensions (W x H x D) mm 717x93x717 717x93x717 717x93x717 717x93x717
Functions
Auto Restart - OOOO
Auto Swing - OOOO
Group/Individual Control - OOOO
External Contact Control - OOOO
Trouble Shooting by LED - OOOO
Standard
Accessories
Installation Manual - OOOO
Operation Manual - XXXX
Pattern Sheet for Installation - OOOO
Flexible Drain Hose - OOOO
Filter / Safety Grille - Filter / Safety Grille Filter / Safety Grille Filter / Safety Grille Filter / Safety Grille
Drain Pump (Pumping speed, lift) ℓ/h,mm 24, 750 24, 750 24, 750 24, 750
Optional
Accessories
Wireless Remote Controller - MR-BH01 MR-BH01 MR-BH01 MR-BH01
Wired Remote
Controller
Simplified - MWR-SH00 MWR-SH00 MWR-SH00 MWR-SH00
Standard - MWR-TH01 MWR-TH01 MWR-TH01 MWR-TH01
Premium - MWR-WS00 MWR-WS00 MWR-WS00 MWR-WS00
External Contact Interface Module - MIM-B14 MIM-B14 MIM-B14 MIM-B14
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.
