Product Specifications
2-18 Samsung Electronics
Indoor Unit(cont.)
QSlim duct
Model
AVXDSH022E6
ND022LHXE6
AVXDSH028E6
ND028LHXE6
AVXDSH036E6
ND036LHXE6
AVXDSH045E6
ND045LHXE6
AVXDSH056E6
ND056LHXE6
Power Supply ø/V/Hz 1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50
Mode*
1)
HP / HR HP / HR HP / HR HP / HR HP / HR
Performance
Capacity
Cooling*
2)
kW 2.2 2.8 3.6 4.5 5.6
Btu/h 7,500 9,500 12,200 15,300 19,100
Heating*
3)
kW 2.5 3.2 4.0 5.0 6.3
Btu/h 8,500 10,900 13,600 17,000 21,400
Condensate (with High fan speed) Liters/h 0.80 1.12 1.28 2.07 2.39
Power
Input W 80 80 80 90 100
Running Current A 0.4 0.4 0.4 0.6 0.6
Sound Level Sound Pressure (High/Low)*
4)
dB(A) 31 / 26 32 / 27 32 / 27 33 / 30 33 / 30
Fan
Type - Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan
Motor
Model - YSK110-25-4SM YSK1 10-25-6SN YSK1 10-25-6SN YSK140-60-4B YSK140-60-4B
Type - Non Feedback SSR Non Feedback SSR Non Feedback SSR Non Feedback SSR Non Feedback SSR
Output W *5) *5) *5) *5) *5)
Airflow Rate
Cooling (High) m
3
/min 8 9 10 14.5 15.5
Heating (High) m
3
/min 9 10 12 16.5 18
External Static Pressure
Standard(Min.~Max)
mmH2O 2 (0~4) 2 (0~4) 2 (0~4) 2 (0~4) 2 (0~4)
Refrigerant
Type - R410A R410A R410A R410A R410A
Control Method - EEV EEV EEV EEV EEV
Temperature Control -
Micom&Thermistors Micom&Thermistors Micom&Thermistors Micom&Thermistors Micom&Thermistors
Safety Devices - Fuse Fuse Fuse Fuse Fuse
Piping
Connections
Liquid (Flare) ø, mm 6.35 6.35 6.35 6.35 6.35
Gas (Flare) ø, mm 12.7 12.7 12.7 12.7 12.7
Drain ø, mm VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25)
Weight
Net Weight kg 26.0 26.0 26.0 31.0 31.0
Shipping Weight kg 31.0 31.0 31.0 39.0 39.0
Dimensions
Net Dimensions (W x H x D) mm 900x199x600 900x199x600 900x199x600 1,100x199x600 1,100x199x600
Shipping Dimensions (W x H x D) mm 1,133x330x730 1,133x330x730 1,133x330x730 1,330x330x730 1,330x330x730
Functions
Auto Restart - O O O O O
Auto Swing - X X X X X
Group/Individual Control - O O O O O
External Contact Control - O O O O O
Trouble Shooting by LED - X X X X X
Standard
Accessories
Installation Manual - O O O O O
Operation Manual - O O O O O
Pattern Sheet for Installation - X X X X X
Flexible Drain Hose - O O O O O
Filter / Safety Grille - Filter (Washable) Filter (Washable) Filter (Washable) Filter (Washable) Filter (Washable)
Drain Pump (Pumping speed, lift) - MR-BH01 MR-BH01 MR-BH01 MR-BH01 MR-BH01
Optional
Accessories
Wireless Remote Controller - MRK-A01 MRK-A01 MRK-A01 MRK-A01 MRK-A01
Duct Receiver Kits
Receiver
- MRW-10A MRW-10A MRW-10A MRW-10A MRW-10A
Receiver Wire
- MWR-SH00 MWR-SH00 MWR-SH00 MWR-SH00 MWR-SH00
Wired Remote
Controller
Simplified - MWR-TH01 MWR-TH01 MWR-TH01 MWR-TH01 MWR-TH01
Standard - MWR-WS00 MWR-WS00 MWR-WS00 MWR-WS00 MWR-WS00
Premium - MIM-B14 MIM-B14 MIM-B14 MIM-B14 MIM-B14
External Contact Interface Module
AVX66
Category
MDP-E075SEE MDP-E075SEE MDP-E075SEE MDP-E075SEE MDP-E075SEE
ND66
Category
MDP-E075SEE3
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.
