Exploded Views and Parts List
Samsung Electronics 5-68
■ Parts List
Q'TY
AVXWVH056E✳
ND056VH✳✳✳
AVXWVH071E✳
ND071VH✳✳✳
AVXWVH022E✳
AVXWVH028E✳
AVXWVH036E✳
ND022VH✳✳✳
ND028VH✳✳✳
ND036VH✳✳✳
No. Code No. Description Specification SA/SNA
1 DB92-01087D ASS'Y PANEL FRONT ASS'Y HALF MIRROR 1 - - SNA
DB92-01086D ASS'Y PANEL FRONT ASS'Y HALF MIRROR - 1 1 SNA
1-1 DB64-01633A PANEL FRONT HIPS,EMPIRE SILVER 1 - - SA
DB64-01638A PANEL FRONT HIPS,EMPIRE SILVER - 1 1 SA
1-2 DB63-01593A FILTER-PRE PP,GRAY 2 - - SA
DB63-01594A FILTER-PRE PP,GRAY - 2 2 SA
1-3 DB64-01634A PANEL-MID HIPS,EMPIRE SILVER 1 - - SA
DB64-01639A PANEL-MID HIPS,EMPIRE SILVER - 1 1 SA
1-4 DB66-01152A LINK-GRILLE POM,WHITE 1 1 1 SA
1-5 DB66-01156A GEAR-RACK POM,WHITE 1 1 1 SA
1-6 DB66-01155A GEAR-PINION POM,WHITE 1 1 1 SA
1-7 DB31-00369B MOTOR STEP ASS'Y 1 1 1 SA
1-8 6002-000588 SCREW-TAP TH M4XL6 3 3 3 SNA
1-9 DB66-01176A LINK-SUPPORT POM,WHITE 4 4 4 SA
1-10 DB61-03139A SPRING ETC-GRILLE STS 1 1 1 SA
1-11 DB63-01630A COVER-DISPLAY ABS-FR(17) 1 1 1 SA
1-12 DB93-04452F ASS'Y DISPLAY ASS'Y 1 1 1 SA
1-13 DB61-02910A FRAME-GRILLE ASS'Y 1 1 1 SA
1-14 DB92-01052A WINDOW-MIRROR ACRYL 1 - - SNA
DB64-01052B WINDOW-MIRROR ACRYL - 1 1 SNA
1-15 DB61-03139B SPING ETC-GRILLE STS 1 1 1 SA
2 DB94-01237A ASS'Y TRAY DRAIN ASS'Y 1 - - SA
DB94-01245A ASS'Y TRAY DRAIN ASS'Y - 1 1 SA
2-1 DB63-01578A TRAY DRAIN ASS'Y 1 - - SA
DB63-01581A TRAY DRAIN ASS'Y - 1 1 SA
2-2 DB61-02908A BLADE-H ABS, EMPIRE SILVER 1 - - SA
DB61-02914A BLADE-H ABS, EMPIRE SILVER - 1 1 SA
2-3 DB61-01636A BLADE-V PP 2 - - SA
DB61-01976A BLADE-V PP - 2 2 SA
2-4 DB73-00180A RUBBER-CAP DRAIN GUM-EPM 1 1 1 SNA
2-5 DB94-00458B ASS'Y DRAIN-HOSE ASS'Y 1 1 1 SA
2-6 DB31-00371A MOTOR STEP ASS'Y 1 - - SA
DB31-00370A MOTOR STEP ASS'Y - 1 1 SA
3 DB63-00844D COVER-TERMINAL HIPS,V0 1 - - SA
DB63-01063C COVER-TERMINAL HIPS,V0 - 1 1 SA
4 DB63-00850A COVER-BEARING ABS,BLACK 1 - - SNA
DB63-01065A COVER-BEARING ABS,BLACK - 1 1 SNA
5 DB96-03149A ASS'Y EVAP-SUPPORT RH ASS'Y 1 - - SA
DB96-03817A ASS'Y EVAP-SUPPORT RH ASS'Y - 1 1 SA
