Exploded Views and Parts List
5-69 Samsung Electronics
■ Parts List(cont.)
Q'TY
AVXWVH056E✳
ND056VH✳✳✳
AVXWVH071E✳
ND071VH✳✳✳
AVXWVH022E✳
AVXWVH028E✳
AVXWVH036E✳
ND022VH✳✳✳
ND028VH✳✳✳
ND036VH✳✳✳
No. Code No. Description Specification SA/SNA
6 DB93-04636B ASS'Y CONTROL IN ASS'Y 1 - - SNA
DB93-04664B ASS'Y CONTROL IN ASS'Y - 1 1 SNA
7 DB90-02167B ASS'Y COVER-CONTROL IN ASS'Y 1 - - SA
DB90-02082A ASS'Y COVER-CONTROL IN ASS'Y - 1 1 SA
8 DB96-07856A ASS'Y EVAP-TOTAL ASS'Y 1 - - SNA
DB96-06587D ASS'Y EVAP-TOTAL ASS'Y - - 1 SNA
DB96-07855A ASS'Y EVAP-TOTAL ASS'Y - 1 - SNA
9 DB67-60030A SPRING-SENSOR STS301 2 2 2 SNA
10 DB94-00455A ASS'Y BEARING-RUBBER ASS'Y 1 1 1 SA
11 DB94-00456A ASS'Y-CROSS FAN ASS'Y 1 - - SA
DB94-00456B ASS'Y-CROSS FAN ASS'Y - 1 1 SA
12 DB31-00219A MOTOR FAN ASS'Y 1 - - SA
DB31-00267A MOTOR FAN ASS'Y - 1 1 SA
13 DB94-01152B ASS'Y-BODY BACK ASS'Y 1 - - SA
DB94-01153B ASS'Y-BODY BACK ASS'Y - 1 1 SA
13-1 DB61-03028A BODY BACK HIPS 1 - - SA
DB61-03029A BODY BACK HIPS - 1 1 SA
13-2 DB93-04230A ASS'Y-COMPACT MPI ASS'Y 1 - - SA
13-3 DB63-01583A COVER-MPI HIPS 1 - - SA
14 DB61-01638B HOLDER-PIPE HIPS 1 - - SA
DB61-01981B HOLDER-PIPE HIPS - 1 1 SA
15 DB67-00499C CAP-SCREW HIPS,EMPIRE SILVER 2 2 2 SA
16 DB97-02851B PLATE-HANGER SGCC-M 1 - - SNA
DB90-02738A PLATE-HANGER SGCC-M - 1 1 SNA
17 DB93-04700S ASS'Y REMOCON ASS'Y 1 1 1 SA
