Exploded Views and Parts List
5-101 Samsung Electronics
■ Parts List
Q'TY
RD080HRXGB
RD080HRXGASTK
RD100HRXGB
RD100HRXGASTK
RD100HRXGB
RD120HRXGASTK
Code No.No. SA/SNA
Description
Specification
1 DB90-05485B ASS'Y COVER TOP ASS'Y 1 1 1 SA
2 DB63-02614A GUARD FAN LARGE PD PD, TOUCH GRAY 1 1 1 SA
3 DB63-02618A COVER TOP PD SMALL PD, TOUCH GRAY 1 1 1 SA
4 DB62-03304B BELLOW MOUTH PP, GRAY 1 1 1 SA
5 DB31-00298A FAN PROPELLER AS+GF20%(BLK) 1 1 1 SA
6 DB31-00330D MOTOR FAN DL-13890SSOC - - 1 SA
DB31-00330E MOTOR FAN DL-13875SSOA 1 1 - SA
7 DB90-02145C ASS'Y BACK BEAMUP 10 ASS'Y 1 1 1 SA
8 DB90-05227B ASS'Y FRONT BEAM UP 12 ASS'Y 1 1 1 SA
9 DB61-02255A BRACKET MOTOR SGHC-HGI, T2.3 2 2 2 SA
10 DB90-02638B ASS'Y PLATE BEAM SIDE LF ASS'Y 2 2 2 SA
11 DB90-05207B ASS'Y CABI BACK UP 10HP ASS'Y 1 1 1 SA
12 DB90-05410A ASS'Y GUARD COND BACK 12HP ASS'Y 1 1 1 SA
13 DB96-14514A ASS'Y COND OUT 12HP ASS'Y 1 1 1 SA
14 DB90-05200B ASS'Y CABINET SIDE RH 20HP ASS'Y 1 1 1 SA
15 DB90-05201B ASS'Y CABINET SIDE LF 20HP ASS'Y 1 1 1 SA
16 DB90-05226C ASS'Y FRONT BEAM CONTROL BOX 12HP ASS'Y 1 1 1 SA
17 DB90-02121F ASS'Y CABI FRONT UP 10HP ASS'Y 1 1 1 SA
18 DB90-05206A ASS'Y CABI FRONT MID 12HP ASS'Y 1 1 1 SA
19 DB63-02406A COVER WINDOW DISPLAY SECC-P, TOUCH GRAY 1 1 1 SA
20 DB64-02368B CABINET FRONT LOW 12HP SECC-P, TOUCH GRAY 1 1 1 SA
21 DB61-04537A PLATE COVER INSTALLATION SECC-P, TOUCH GRAY 1 1 1 SA
22 DB90-06719A ASS'Y CABINET CONTROL BOX ASS'Y 1 1 1 SA
23 DB61-04527A CASE HUB PCB ABS, 5VA 1 1 1 SA
24 DB61-04528A CASE CONTROL MAIN ABS, 5VA 1 1 1 SA
25 DB63-02725A COVER FAN WIRE ABS, 5VA 1 1 1 SA
26 DB64-02794A CABINET CONTROL BOX SGCC-M, 0.8T 1 1 1 SA
27 DB93-12482B ASS'Y PCB MAIN OUT ASS'Y 1 1 1 SA
28 DB93-11518A ASS'Y PCB SUB-SENSOR ASS'Y 1 1 1 SA
29 DB63-02452A COVER FUSE ABS, 5VA 2 2 2 SA
30 DB93-11209C ASS'Y PCB MAIN HUB ASS'Y 1 1 1 SA
31 DB90-05865A ASS'Y COVER CONTROL BOX ASS'Y 1 1 1 SA
32 DB90-03829B ASS'Y WINDW DISPLAY ASS'Y 1 1 1 SA
33 DB93-12535C ASS'Y BLDC EMI DRIVER ASS'Y 1 1 1 SA
34 DB96-14614A ASS'Y TUBE 4WAY GAS BALL HR 8HP ASS'Y 1 - - SA
DB96-14615A ASS'Y TUBE 4WAY GAS BALL HR 10HP ASS'Y - 1 - SA
DB96-14616A ASS'Y TUBE 4WAY GAS BALL HR 12HP ASS'Y - - 1 SA
35 DB96-14633A ASS'Y TUBE 4WAY VALVE HR 10HP ASS'Y 1 1 - SA
DB96-14384A ASS'Y TUBE 4WAY VALVE HR 12HP ASS'Y - - 1 SA
36 DB96-14627A ASS'Y TUBE MAIN COOLING VALVE 12HP ASS'Y 1 1 1 SA
37 DB96-14625A ASS'Y TUBE LIQUID BALL HR EEV 10HP ASS'Y 1 1 - SA
DB96-14383A ASS'Y TUBE LIQUID BALL HR EEV 12HP ASS'Y - - 1 SA
38 DB96-14619A ASS'Y TUBE HR GAS BALL VALVE 8HP ASS'Y 1 - - SA
DB96-14620A ASS'Y TUBE HR GAS BALL VALVE 10HP ASS'Y - 1 - SA
DB96-14621A ASS'Y TUBE HR GAS BALL VALVE 12HP ASS'Y - - 1 SA
