Exploded Views and Parts List
Samsung Electronics 5-102
■ Parts List(cont.)
Q'TY
RD080HRXGB
RD080HRXGASTK
RD100HRXGB
RD100HRXGASTK
RD100HRXGB
RD120HRXGASTK
Code No.No. SA/SNA
Description
Specification
39 DB96-14400A ASS'Y TUBE SUBCOOLER HR 12HP ASS'Y 1 1 1 SA
40 DB96-15589A ASS'Y TUBE EVI BYPASS EU 12HP ASS'Y 1 1 1 SA
41 DB96-14245A ASS'Y TUBE HOT GAS VALVE 20HP ASS'Y 1 1 1 SA
42 DB96-15591A ASS'Y TUBE OIL GAS VALVE EU 12HP ASS'Y 1 1 1 SA
43 DB96-14392A ASS'Y TUBE LIQUID BYPASS VALVE HR 12HP ASS'Y 1 1 1 SA
44 DB96-14391A ASS'Y TUBE EXPANSION VALVE HR 12HP ASS'Y 1 1 1 SA
45 DB96-14429A ASS'Y TUBE SUCTION PWM VALVE 12HP ASS'Y 1 1 1 SA
46 DB96-15587A ASS'Y TUBE OIL RETURN EU 12HP ASS'Y 1 1 1 SA
47 DB96-14233A ASS'Y TUBE OIL SEPA OUT 10HP ASS'Y 1 1 - SA
DB96-14228A ASS'Y TUBE OIL SEPA OUT 12HP ASS'Y - - 1 SA
48 DB96-15002A ASS'Y TUBE VAPOR INJECTION EU 12HP ASS'Y 1 1 1 SA
49 DB96-15588A ASS'Y TUBE OIL BALANCE VALVE EU 12HP ASS'Y 1 1 1 SA
50 DB96-15590A ASS'Y TUBE DISCHARGE EU 12HP ASS'Y 1 1 1 SA
51 DB96-14974A ASS'Y OIL SEPARATOR FELT 12HP ASS'Y 1 1 1 SA
52 DB96-14261A ASS'Y ACCUMULATOR 12HP ASS'Y 1 1 1 SA
53 DB95-01468C ASS'Y COMP EVI ZPJ61KCE-TFD-496 1 1 - SA
DB95-01468E ASS'Y COMP EVI ZPJ83KCE-TFD-496 - - 1 SA
54 DB95-01456C ASS'Y COMP EVI ZPI61KCE-TFD-496 1 1 - SA
DB95-01456E ASS'Y COMP EVI ZPI83KCE-TFD-496 - - 1 SA
55 DB97-15950A ASS'Y CLOTH COMP SOUND SIDE COMP FELT, 1st 1 1 1 SA
56 DB97-15951A ASS'Y CLOTH COMP SOUND SIDE COMP FELT, 2nd 1 1 1 SA
57 DB63-02031A COVER COMP SOUND TOP COMP COVER, 1st 1 1 1 SA
58 DB63-02032A COVER COMP SOUND TOP COMP COVER, 2nd 1 1 1 SA
59 DB95-00766P ASS'Y COMP HEATER ASS'Y 1 1 1 SA
60 DB95-00766Q ASS'Y COMP HEATER ASS'Y 1 1 1 SA
61 DB95-04691A ASS'Y THEMISTOR 2COMP TOTAL ASS'Y 1 1 1 SA
62 DB95-04537C ASS'Y THEMISTOR SUMP1 EVI EVO SUMP1 EVI EVO 1 1 1 SA
63 DB95-04538C ASS'Y THEMISTOR SUMP2 DIS2 SUC LIQ SUMP2 DIS2 SUC LIQ 1 1 1 SA
64 DB95-04539C ASS'Y THEMISTOR DIS1 OIL CONOUT DIS1 OIL CONOUT 1 1 1 SA
65 DB93-10867B ASS'Y CONNECTOR WIRE COMP TOTAL ASS'Y 1 1 1 SA
66 DB93-10834D ASS'Y CONNECTOR WIRE COMP COMP 1st 1 1 1 SA
67 DB93-10834E ASS'Y CONNECTOR WIRE COMP COMP 2nd 1 1 1 SA
68 DB90-06138A ASS'Y CABINET POWER BOX ASS'Y 1 1 1 SA
69 DB65-00232C TERMINAL BLOCK 3PHASE 3PHASE 1 1 1 SA
70 DB90-03795A ASS'Y SUPPORT WIRE ASS'Y 1 1 1 SA
71 DB61-03441A SUPPORT WIRE BODY ABS, 5VA 1 1 1 SA
72 DB61-03442A SUPPORT WIRE COVER ABS, 5VA 1 1 1 SA
73 DB90-05866A ASS'Y COVER POWER BOX ASS'Y 1 1 1 SA
74 DB65-00179D TERMINAL BLOCK COMM 1 1 1 SA
75 DB61-04526A CASE TERMINAL ABS, 5VA 1 1 1 SA
76 DB93-12483A ASS'Y PCB SUB-EEPROM ASS'Y 1 1 1 SA
