Exploded Views and Parts List
5-117 Samsung Electronics
■ Parts List
Q'TY
RD160HRXGB
RD160HRXGASTK
RD180HRXGB
RD180HRXGASTK
RD200HRXGB
RD200HRXGASTK
Code No.No. SA/SNA
Description
Specification
1 DB90-05487A ASS'Y COVER TOP ASS'Y 2 2 2 SA
2 DB63-02615A GUARD FAN PD, TOUCH GRAY 2 2 2 SA
3 DB63-02617A COVER TOP 20HP PD, TOUCH GRAY 2 2 2 SA
4 DB62-07398A BELLOW MOUTH PP, GRAY 2 2 2 SA
5 DB90-05199B ASS'Y CABI UPPER LF 20HP ASS'Y 4 4 4 SA
6 DB90-05218A ASS'Y CABINET BEAM BACK 20HP ASS'Y 1 1 1 SA
7-1 DB90-05409A ASS'Y GUARD COND BACK RH 20HP ASS'Y 1 1 1 SA
7-2 DB90-05408A ASS'Y GUARD COND BACK LF 20HP ASS'Y 1 1 1 SA
8 DB67-00983A FAN PROPELLER AS+GF20%(BLK) 2 2 2 SA
9 DB31-00558C FAN MOTOR DAO165560ZRC, WHT 1 1 1 SA
10 DB31-00558D FAN MOTOR DAO165560ZRC, BLU 1 1 1 SA
11 DB61-02255A BRACKET MOTOR SGHC-HGI, T2.3 4 4 4 SA
12 DB90-05224B ASS'Y FRONT BEAM UP 20HP ASS'Y 1 1 1 SA
13 DB90-05223A ASS'Y BACK BEAM UP 20HP ASS'Y 1 1 1 SA
14 DB96-14515A ASS'Y COND OUT16HP ASS'Y 1 - - SA
DB96-14515A ASS'Y COND OUT20HP ASS'Y - 1 1 SA
DB96-14985A ASS'Y COND OUT22HP ASS'Y - - - SA
15 DB90-05200B ASS'Y CABINET SIDE RH 20HP ASS'Y 1 1 1 SA
16 DB90-05201B ASS'Y CABINET SIDE LF 20HP ASS'Y 1 1 1 SA
17 DB90-05225C ASS'Y FRONT BEAM CONTROL BOX 20HP ASS'Y 1 1 1 SA
18 DB90-05867A ASS'Y FRONT BEAM POWER BOX ASS'Y 1 1 1 SA
19 DB90-05197A ASS'Y CABI FRONT MID LF 20HP ASS'Y 1 1 1 SA
20 DB90-05194B CABI FRONT LOW LF SECC-P, TOUCH GRAY 1 1 1 SA
21-1 DB90-05195A ASS'Y CABI FRONT MID RH 20HP ASS'Y 1 1 1 SA
21-2 DB63-02406A COVER WINDOW DISPLAY SECC-P, TOUCH GRAY 1 1 1 SA
22 DB90-05193C ASS'Y CABI FRONT LOW RH ASS'Y 1 1 1 SA
23 DB90-05219A ASS'Y CABINET BEAM FRONT 20HP ASS'Y 1 1 1 SA
24 DB61-04537A PLATE COVER INSTALLATION SECC-P, TOUCH GRAY 1 1 1 SA
25 DB90-06719A ASS'Y CABINET CONTROL BOX ASS'Y 1 1 1 SA
26 DB61-04527A CASE HUB PCB ABS, 5VA 1 1 1 SA
27 DB61-04528A CASE CONTROL MAIN ABS, 5VA 1 1 1 SA
28 DB63-02725A COVER FAN WIRE ABS, 5VA 1 1 1 SA
29 DB64-02794A CABINET CONTROL BOX SGCC-M, 0.8T 1 1 1 SA
30 DB93-12482B ASS'Y PCB MAIN OUT ASS'Y 1 1 1 SA
31 DB93-11518A ASS'Y PCB SUB-SENSOR ASS'Y-#1,#2COMP 1 1 1 SA
32 DB93-11519B ASS'Y PCB SUB-SENSOR-LOW ASS'Y,#3COMP 1 1 1 SA
33 DB63-02452A COVER FUSE ABS, 5VA 3 3 3 SA
34 DB93-11209B ASS'Y PCB MAIN HUB ASS'Y 1 1 1 SA
35 DB90-05865A ASS'Y COVER CONTROL BOX ASS'Y 1 1 1 SA
36 DB90-03829B ASS'Y WINDW DISPLAY ASS'Y 1 1 1 SA
37 DB93-12535D ASS'Y BLDC EMI DRIVER ASS'Y 1 1 1 SA
38 DB96-14532A ASS'Y TUBE 4WAY GAS BALL VALVE 16HP 1 - - SA
DB96-14533A ASS'Y TUBE 4WAY GAS BALL VALVE 20HP ASS'Y - 1 1 SA
39 DB96-14259A ASS'Y TUBE 4WAY VALVE 16HP 1 - - SA
DB96-14260A ASS'Y TUBE 4WAY VALVE 20HP ASS'Y - 1 1 SA
40 DB96-14211A ASS'Y TUBE GAS BALL VALVE 20HP ASS'Y 1 1 1 SA
41 DB96-14542A
ASS'Y TUBE SUBCOOLLER LIQUID BALL VALVE 16HP
1 - - SA
DB96-14543A
ASS'Y TUBE SUBCOOLLER LIQUID BALL VALVE 20HP
ASS'Y - 1 1 SA
