Exploded Views and Parts List
Samsung Electronics 5-118
■ Parts List(cont.)
Q'TY
RD160HRXGB
RD160HRXGASTK
RD180HRXGB
RD180HRXGASTK
RD200HRXGB
RD200HRXGASTK
Code No.No. SA/SNA
Description
Specification
42 DB96-14216A ASS'Y TUBE LIQUID BALL VALVE 16HP 1 - - SA
DB96-14217A ASS'Y TUBE LIQUID BALL VALVE 20HP ASS'Y - 1 1 SA
43 DB96-14213A ASS'Y TUBE SUBCOOLER 16HP 1 - - SA
DB96-14214A ASS'Y TUBE SUBCOOLER 20HP ASS'Y - 1 1 SA
44 DB96-15600A ASS'Y TUBE EVI BYPASS EU 20HP ASS'Y 1 1 1 SA
45 DB96-14247A ASS'Y TUBE LIQUID BYPASS VALVE 20HP ASS'Y 1 1 1 SA
46 DB96-14252A ASS'Y TUBE OIL GAS VALVE 20HP ASS'Y 1 1 1 SA
47 DB96-14231A ASS'Y TUBE OIL RETURN 20HP ASS'Y 1 1 1 SA
48 DB96-15598A ASS'Y TUBE SUCTION PWM VALVE 20HP ASS'Y 1 1 1 SA
49 DB96-14262A ASS'Y ACCUMULATOR 20HP ASS'Y 1 1 1 SA
50 DB96-14230A ASS'Y TUBE OIL SEPA OUT 16HP 1 - - SA
DB96-14232A ASS'Y TUBE OIL SEPA OUT 20HP ASS'Y - 1 1 SA
51 DB96-14962A ASS'Y TUBE VAPOR INJECTION EU 20HP ASS'Y 1 1 1 SA
52 DB96-15601A ASS'Y TUBE DISCHARGE EU 20HP ASS'Y 1 1 1 SA
53 DB96-15368A ASS'Y FELT OIL SEPARATOR 20HP ASS'Y 1 1 1 SA
54 DB96-14961A ASS'Y TUBE OIL BALANCE VALVE EU 20HP ASS'Y 1 1 1 SA
55 DB96-15675A ASS'Y TUBE HOT GAS VALVE 20HP ASS'Y 1 1 1 SA
56 DB96-14242A ASS'Y TUBE EXPANSION VALVE 16HP 1 - - SA
DB96-14243A ASS'Y TUBE EXPANSION VALVE 20HP ASS'Y - 1 1 SA
57 DB95-01468D ASS'Y COMP EVI ZPJ72KCE-TFD-496 1 - - SA
DB95-01468E ASS'Y COMP EVI ZPJ83KCE-TFD-496 - 1 1 SA
58 DB95-01456D ASS'Y COMP EVI ZPI72KCE-TFD-496 2 - - SA
DB95-01456E ASS'Y COMP EVI ZPI83KCE-TFD-496 - 2 2 SA
59 DB97-15950A ASS'Y CLOTH COMP SOUND SIDE COMP FELT, 1st 1 1 1 SA
60 DB97-15951A ASS'Y CLOTH COMP SOUND SIDE COMP FELT, 2nd,3rd 2 2 2 SA
61 DB63-02031A COVER COMP SOUND TOP COMP COVER, 1st 1 1 1 SA
62 DB63-02032A COVER COMP SOUND TOP COMP COVER, 2nd,3rd 2 2 2 SA
63 DB95-00766P ASS'Y COMP HEATER ASS'Y 1 1 1 SA
64 DB95-00766Q ASS'Y COMP HEATER ASS'Y 1 1 1 SA
65 DB95-00766R ASS'Y COMP HEATER ASS'Y 1 1 1 SA
66 DB95-04564A ASS'Y THEMISTOR 3COMP TOTAL ASS'Y 1 1 1 SA
67 DB95-04537A ASS'Y THEMISTOR SUMP1 EVI EVO SUMP1 EVI EVO 1 1 1 SA
68 DB95-04538A ASS'Y THEMISTOR SUMP2 DIS2 SUC LIQ SUMP2 DIS2 SUC LIQ 1 1 1 SA
69 DB95-04539A ASS'Y THEMISTOR DIS1 OIL CONOUT DIS1 OIL CONOUT 1 1 1 SA
70 DB95-04540A ASS'Y THEMISTOR DIS3 SUMP3 DIS3 SUMP3 1 1 1 SA
71 DB93-10867A ASS'Y CONNECTOR WIRE COMP TOTAL ASS'Y 1 1 1 SA
72 DB93-10834A ASS'Y CONNECTOR WIRE COMP COMP 1st 1 1 1 SA
73 DB93-10834B ASS'Y CONNECTOR WIRE COMP COMP 2nd 1 1 1 SA
74 DB93-10834C ASS'Y CONNECTOR WIRE COMP COMP 3rd 1 1 1 SA
75 DB90-06138A ASS'Y CABINET POWER BOX ASS'Y 1 1 1 SA
76 DB65-00232C TERMINAL BLOCK 3PHASE 3PHASE 1 1 1 SA
77 DB90-03795A ASS'Y SUPPORT WIRE ASS'Y 1 1 1 SA
78 DB61-03441A SUPPORT WIRE BODY ABS, 5VA 1 1 1 SA
79 DB61-03442A SUPPORT WIRE COVER ABS, 5VA 1 1 1 SA
80 DB90-05866A ASS'Y COVER POWER BOX ASS'Y 1 1 1 SA
81 DB65-00179D TERMINAL BLOCK COMM 1 1 1 SA
82 DB61-04526A CASE TERMINAL ABS, 5VA 1 1 1 SA
83 DB93-12483A ASS'Y PCB SUB-EEPROM ASS'Y 1 1 1 SA
